Best Andon board and display System

The Andon board and display are very effective in making the real time monitoring of the production system. The Andon Boards works in tandem with Andon System connected with the machine in the shop floor. The Andon system gives status to the Andon Display boards on real time. The Display boards allow the operators, supervisors and the management executive to get the real understanding of the performance of the machines.

Features of Andon board and display:

  • Product Name running on production can be displayed
  • Machine’s status such as Running/Stopped/No plan can be displayed
  • Production count can be displayed
  • Real time production target and Real time Production achieved can be indicated through boards and displays
  • Downtime can be decreased by timely escalations and alerts to the senior management

Andon production Boards allows the management executive to get bird’s eye view of the status of all the machines in a single view.

Why Andon board is important?

Reduce downtime

Identify and fix defects as soon as possible

Encourages continuous improvement in your team

Maximizes the overall productivity and efficiency

Architecture for Andon Board and display:

andon board and display

Product Specification

Part NumberADEA01
DescriptionEnterprise Andon
Supply Voltage24 vdc
Supply Current2 A
Operating Temperature Range-40 to 800 C (industrial)
Dimension 120 mm x 180 mm(W X H)
Features·         Three tier tower lamp·   ·         Andon Server kit ·         Andon Client kit ·         Big Display on production line ·         Production Monitoring tool ·         Industrial Wireless Connectivity ·         Automatic Email alert ·         Automatic SMS alert ·         Automatic Escalation process ·         Advanced report like MTTR/MTBF ·         Shiftwise Production Report/Custom Report ·         Individual Issue code according to the Machine
Hardware·         ANDON Terminal with Tower lamp·         Andon Server Terminal   ·         HP Server with SQL Server & Windows Server operating System
Software·         Efficio Software
Accessories·         Production Display Monitor,         Buzzer

Application of Andon System across Industries:

Ready to take your next step?

Implement Andon to Reduce Downtime. The Andon boards can be customized according to the requirement of the customer
